FSK Tape Description



Foil Scrim Kraft Tape combines a layer of aluminum foil, a layer of fiberglass scrim reinforcement, and a layer of kraft paper backing with an adhesive. The FSK tape features a strong adhesive that ensures a secure bond to various surfaces, including metal, plastic, and insulation materials. It is designed to withstand a range of temperatures, making it suitable for HVAC applications.

The aluminum foil layer provides the tape with excellent thermal insulation properties, moisture barrier capabilities, and resistance to heat and light. The fiberglass scrim reinforcement enhances the tape's strength, tear resistance, and dimensional stability, making it suitable for applications requiring durability and support. The kraft paper layer is used as a backing material in FSK tape. Kraft paper adds additional strength and stability to the tape, making it easier to handle and apply in various applications.

This Foil Scrim Kraft Tape features a robust 120-micron backing that ensures durability, complemented by a total thickness of 170 microns for enhanced resistance to wear, moisture, and environmental conditions. Renowned for its strength, moisture resistance, and capability to endure extreme temperatures, this tape is particularly suited for environments where both durability and performance are crucial.

Tape Applications:

Foil scrim kraft tape provides an effective solution for sealing and insulating surfaces in construction, HVAC, packaging, and other sectors where airtightness and moisture control are essential.

HVAC Systems : FSK tape is commonly used in HVAC systems for sealing and insulating ductwork, joints, and seams to prevent air leakage, improve energy efficiency, and maintain indoor air quality.

Insulation: It is used in insulation applications for sealing and joining insulation materials such as fiberglass, mineral wool, and foam boards to create a thermal barrier and prevent heat loss or gain.

Vapor Barrier: FSK tape acts as a vapor barrier when applied to insulation materials, helping to control moisture transmission and prevent condensation within walls, ceilings, and floors.

Sealing: The tape is used for sealing and repairing leaks in pipes, vents, and other components in industrial, commercial, and residential settings.

Construction: It is used in construction projects for sealing seams in building wraps, vapor barriers, and reflective insulation materials.

Tape Features:

  • High strength and durability
  • Excellent tear resistance
  • Good heat reflection and insulation properties
  • Moisture barrier and corrosion protection
  • Easy to apply and remove
  • Peel-back design for easy application
  • Moisture-, mold-, and UV-resistant design

FSK Tape Technical Data

Tape Properties:

PROPERTIES

METRIC

ENGLISH

TEST METHOD

Backing Thickness

120Micron

4.8Mil

PSTC-133 / ASTM D 3652

Total Thickness

170 Micron

6.8Mil

PSTC-133 / ASTM D 3652

Adhesion to Steel

20N/25mm

72Oz./In.

PSTC-101 / ASTM D 3330

Tack Rolling Ball

15cm

6.0In.

PSTC-6 / ASTM D 3121

Tensile Strength

120 N/25mm

27.3Lb/In

PSTC-131 / ASTM D 3759

Elongation

2.0%

2.0%

PSTC-131 / ASTM D 3759

Service Temperature

-20℃ to +80℃

-4℉ to +176℉



Applying Temperature

+10℃ to +40℃

+50℉ to +105℉



Tape Roll Size:

Finish Roll:

50mm x 50m 2” x 55yds
75mm x 50m 3” x 55yds

Log Roll: 1200mm x 50m

Jumbo Roll: 1200mm x 900m
